Name: JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-13.5-SC-SC1
Availability: InStock

Rumah > Produk > peredam kejut karet >

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Damping Ratio 0.5 Rubber Shock Absorber

1 Year Warranty Vibration Isolator

60mm Length Friction Damping Vibration Isolator

Tempat asal:

CINA

Nama merek:

Hoan

Nomor model:

JZP-13.5-SC-SC1

Hubungi Kami

Minta Kutipan

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Rincian produk

Panjang:

60mm

Isolasi getaran:

Hingga 90%

Kualitas:

Kelas Industri

Lubang pemasangan:

Instalasi:

Dinding dipasang

Jenis isolasi getaran:

Pasif

Rasio redaman:

0,5

Jaminan:

1 tahun

Perlawanan:

Kimia, Panas, dan Cuaca

Resistensi suhu:

Dapat menahan suhu tinggi dan rendah

Kekakuan aksial:

50n/mm

Jenis pemasangan:

Berulir

Setelah layanan garansi:

Dukungan online

Menyoroti:

Damping Ratio 0.5 Rubber Shock Absorber

1 Year Warranty Vibration Isolator

60mm Length Friction Damping Vibration Isolator

Syarat Pembayaran & Pengiriman

Kuantitas min Order

Syarat-syarat pembayaran

MoneyGram, Western Union, T/T, D/P, D/A, L/C.

Produk terkait

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Dapatkan Harga Terbaik

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

Dapatkan Harga Terbaik

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Dapatkan Harga Terbaik

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

Dapatkan Harga Terbaik

Hubungi Kami

86-29-88292913

Hubungi Sekarang

Deskripsi Produk

Sustainable Manufacturing Made Easy with JZP-13.5-SC-SC1 Rubber Shock Absorber

JZP-SC-SC1 Series: The Eco-Friendly Vibration Isolation Solution

As green manufacturing becomes a global priority, industrial components must demonstrate environmental responsibility throughout their lifecycle. The JZP-SC-SC1 series friction damping vibration isolators from Xi'an Hoan Microwave combine exceptional durability with sustainable features including maintenance-free operation and zero pollution.

Key Environmental Benefits

Extended Service Life: Metal construction ensures durability that typically outlasts the equipment it protects, minimizing replacement waste
Zero Energy Consumption: Passive mechanical design eliminates electricity needs and prevents emissions during operation
Maintenance-Free Operation: Saves on lubricants, cleaning agents, and labor costs while reducing environmental impact
Pollution Prevention: No risk of hydraulic fluid leaks compared to conventional dampers

Dimension Specifications

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	b (mm)
JZP-SC-SC1	60	36	24.5	50	60	M5	∅5.5	5	28

Technical Parameters

Model	Nominal Load (KG)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Limited Period
JMZ-3.2-SC-SC1	3.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-4.2-SC-SC1	4.2
JMZ-5.2-SC-SC1	5.2
JMZ-6.0-SC-SC1	6.0
JMZ-7.0-SC-SC1	7.0
JZP-7.5-SC-SC1	7.5
JZP-9.0-SC-SC1	9.0
JZP-10.5-SC-SC1	10.5
JZP-13.5-SC-SC1	13.5
JZP-15-SC-SC1	15
